User Manual

99-8262HG
®
Kit Assembly
(Figure A)
(Figure B)
(Figure C)
ISO DIN radio provision with pocket
1. Attach the pocket to the radio brackets using the (4) #8 x 3/8”
Phillips screws provided. (Figure A)
2. Remove the metal DIN sleeve and trim ring from the
aftermarket radio.
3. Slide the radio into the bracket/pocket assembly and then
secure it using the screws supplied with the radio. (Figure B)
4. Attach the radio/pocket assembly to the back of the radio trim
panel using the (4) #8 x 3/8” screws provided. (Figure C)
5. Locate the factory wiring harness and antenna connector in
the dash and complete all necessary connections to the radio.
Metra recommends using the proper mating adapter from
Metra and/or Axxess.
Caution! Be sure to plug in the passenger airbag light before
proceeding.
6. Turn the key on and test the radio for proper operation.
7. Secure the completed assembly into the dash using the factory
screws.
8.
Reassemble the dash in the reverse order of disassembly .
3
