DASH DISASSEMBLY

1. Open the passenger door, then unclip

and remove the panel on the side of the

dashboard. Remove (1) Phillips screw

exposed. (Figure A)

2. Unclip and remove the dashboard trim

panel above the glovebox. (Figure B)

3. Unclip and remove the dashboard trim

panel between the steering column and

the radio. (Figure B)

4. Remove (4) screws securing the radio.

Slide the radio out, then unplug and

remove the radio. (Figure C)

Continue to Kit Assembly

(Figure A)

(Figure C)

(Figure B)
