FLUME SELECTION
The
FLUME SELECTION menu will only appear in FLOW mode.
Use È and Æ to select the correct Flume or Weir.
Use È and Æ again to select the Size then È to
Store? and Æ to Yes.
Press È or Ç to store flume selection and get to
CALIBRATION mode.
CUSTOM FLUMES: Experimental or empirical data for any flume or weir can be reduced to an
equation of the form
Q=KHn where:
Q is flow volume
K is as scaling factor which includes flume size and units of flow measurement
n describes the flume non-linearity
H is the level being measured
Use the AquaMetrix Utility program
FIND K&n.exe to determine K and n constants from entered data.
Select
CUSTOM for flumes or weirs not listed in the Menu. At the K: prompt enter a 'K' constant. At the
n: enter an 'n' constant.
AquaMetrix
Ultrason
Page 9
Store? Yes
CALIBRATION
FLUME SELECTION
FLOW MODE ONLY
V-Notch More> P. Bowlus More> L.Lagco More> Rect. Weir > Rect.Weir w/EC > Custom More>
22.5 30 45 60 09
4" 6" 8" 10">
12" 15" 18">
21" 24" 42">
6" 8" 10" 12" >
18" 24" 30" 36">
Size 1.000 ft
Size 1.000 ft
K = 1.0000
N = 1.0000
Parshall More>
2" 3" 6" 9" >
12" 18" 24" 36">
UNITS/MODE
