Owner's manual

RUN
A scrolling display shows the units selected from the
UNITS/MODE column, the mode of operation (Range, Level or
Flow), the full scale value for the large numeric display, Totalizer
value (in
FLOW mode), and air temperature at the sensor location.
ECHO CONFIDENCE
Echo Strength is automatically adjusted by the Ultrason in response
to operating conditions in the applications.
From RUN use È to get to the Echo Confidence display,
EC.
TOTALIZER
The Totalizer display will only be enabled when the Ultrason is calibrated in
FLOW mode. From RUN
use È or Ç keys to display Tot: value. The Totalizer value is updated every 2 seconds with flow
volume > 1 litre (0.264 USG). The display will show up to 10 digits and then restart at 0 automatically.
Press È or Ç keys to return to
RUN.
The totalizer can be reset to zero by going Æ to
SPECIAL FUNCTION and È to Reset Tot?.
RELAY STATUS DISPLAY
Press È from
Tot: to RELAYS 1,2,3.
Engerized relays will be displayed in reverse type
RELAYS:
PASSWORD
The password (a number from
00 to 99) prevents unauthorized access to the
CALIBRATION menu.
From
RUN (scrolling display) press Æ to PASSWORD.
Press Æ to place the cursor under the digits and È or Ç to change the
number and then Æ to proceed to
CALIBRATION.
Factory default Password is
00. A new password can be stored by going Æ to SPECIAL FUNCTION
and È to New Password.
AquaMetrix
Ultrason
Page 6
