Press È to Interval and Æ to the Sec/Min column. Press È or Ç to set the logging time interval.
Choose:
30 Sec
10 Sec
5 Sec
2 Sec
1 Sec
30 Min
10 Min
5 Min
2 Min
1 Min
Press Æ to return to Interval and press È to Reset Log? To erase all existing data in the log press
Æ to
Yes and È. To keep existing data in the Log press È from Reset Log? If you have made
changes to the Start Date, Time or Interval, the data logger will automatically start a new “session”. The
Ultrason will display “
xxxxx Hrs/Days Left”.
From the
xxxxx Hrs Left display press È to Store? Yes. Press Æ to Yes and then È to save
your Data Logging setup, or press È from
Store? to cancel changes made above and exit without
storing changes.
From the Data Logging
Store? Yes prompt the menu will return to RUN STOP SETUP. Press Æ to
position the cursor under
RUN and press È to activate the Data Logger to start. The Ultrason will
display
SESSION NO. x. Press È to return to DATA LOGGING.
Logging "Sessions"
Each time you select
STOP in the DATA LOGGING menu, the Data Logger stores the current data in
memory as a "
SESSION NO" automatically numbered from "1"to"10". If you resume logging by
selecting
RUN, the Data Logger will report that a new logging session is started and titled "SESSION
NO xx
". When you download the logger files to your PC using AquaMetrix Logger software, each
Session will open as a separate graph/table titled "AquaMetrix Data Log xx".
Important:
If you
STORE instrument calibration changes under the UNITS/MODE or CALIBRATON menus, STOP
the data logger and select RUN again to start a new logging Session with your new calibration values.
