Owner's manual

SPECIAL FUNCTIONS
SLT32 V2.26 shows software version installed
View Codes? Yes
Select Yes and then È to display an
instrument performance code. Faults detected
by the instrument are stored in the code and
will be requested by AquaMetrix if you call
for service or assistance.
Tag Enter Instrument Tag number (0-9999)
Date MM DD/YYYY
(with optional Data Logger) Press Æand Ç or
È to change Month, Day Year.
Time HH:MM:SS
(with optional Data Logger) Press Æ and Ç or
È to change Hours, Minutes, Seconds
LOE TIME
Press Æ and Ç or È to change the number of
seconds without receiving an echo before the
Ultrason displays
ECHO LOSS, and Control
relays change state as calibrated under Relay
Parameters.
Factory default is 30 seconds and is
recommended for most applications,
Minimum is 10 seconds and maximum is 60
seconds.
Reset Tot? Yes (FLOW mode only) Position the cursor under
Yes to reset the totalizer. Store this selection
at the
Store? Yes prompt.
Temp 25.0°C Indicates current temperature at the sensor
head. Press Æ to
Min Temp and Æ to Max
Temp
to display the minimum and maximum
temperatures the Ultrason has sensed. Press Æ
to Display °
C °F. Position the cursor under °C
for celcuis display or °F for Farenheight
display. Press È to return to
Temp.
ISB?: No Yes Select Yes only when the instrument is equipped with an optional Intrinsic
Safety Barrier for sensor mounting in hazardous locations. This setting
compensates for the electrical characteristics of an Intrinsic Safety Barrier.
AquaMetrix
Ultrason
Page 15
SPECIAL FUNCTION
SLT32 V 2.26
Tag 01
Date May 31/1999
Time 23:39:51
LOE Time 30 s
Reset Tot? Yes
Temp 20.3 Cº
Simul 0.00%
4mA ADJ 4.000
20mA ADJ 20.000
New Password: 00
Com 24 48 96 192
Store? Yes
Min Temp 20.0 Cº
Max Temp 23.0 Cº
DISPLAY FCºº
VYiew Codes? es
1234567890123456
ISB?: N Yeso
