User`s manual

Rev. 1.00
- 20 -
Metapace T-1
4. Specifications
Printing Method Thermal Line Printing
Dot Density 180 dpi (7dots/mm)
Printing Width 72 mm
Paper Width 80 mm
Characters Per Line (default) 42 (Font A)
56 (Font B)
Printing Speed 46.2 lines/sec , 150 mm/sec
Input Buffer Size 4 KBytes
NOTE※ : Printing speed may be slower, depending on the data transmission
speed and the combination of control commands.
SMPS Input Voltage 100~240 VAC
Frequency
50/60 Hz
Supply
Voltage
SMPS Output Voltage
24 VDC
Temperature
0 ~ 45 (Operating)℃
-10 ~ 50 (Storage)℃
Environmental
Conditions
Humidity 30 ~ 80 % RH (Operating)
10 ~ 90 % RH (Storage)
; Except for paper
Mechanism Head
150 Km
LIFE *
Auto Cutter 1,500,000 Cut
MCBF * Mechanism 37,000,000 lines
* These values are calculated under printing level 2 using recommended paper at normal
temperature.
* These values may vary with environment temperature, printing level, etc.
