User`s manual

Rev. 1.00
- 12 -
Metapace T-1
1-4 Setting the Dip Switches
1-4-1 Serial Interface
SW Function ON OFF Default
1 Auto Line Feed Enable Disable OFF
2 Reserved - - OFF
3 Flow Control XON/OFF DTR/DSR OFF
4 Data Length 7 bits 8 bits OFF
5 Parity Check Yes No OFF
6 Parity Selection EVEN ODD OFF
7 ON
8
Baud Rate Selection Refer to the Following Table
OFF
DIP Switch Setting 1 Function
Transmission Speed SW – 7 SW – 8
9600 Baud ON OFF
19200 Baud OFF OFF
38400 Baud ON ON
57600 Baud OFF ON
Baud Rate Selection
SW Function ON OFF Default
1 Emulation STAR EPSON OFF
2 Internal Bell Control
Internal Bell
Disabled
Internal Bell
Enabled
OFF
3 Auto Cutter Selection Disable Enable OFF
4 Busy Condition Input Buffer Full
• Offline
• Input Buffer Full
OFF
5 OFF
6
Select Print Density Refer to the Following Table
OFF
7 Near End Sensor Status Disable Enable OFF
8 Reserved - - OFF
DIP Switch Setting 2 Function
Print Density SW - 5 SW – 6
1 ( Light ) ON ON
2 OFF OFF
3 ON OFF
4 ( Dark ) OFF ON
Select Print Density
