Specification Sheet

Specifications and
dimensions subject to
change without notice.
Eaton
1121 Highway 74 South
Peachtree City, GA 30269
P: 770-486-4800
www.eaton.com/lighting
HBLED SE
HBLED-LD5-24SE-
W-UNV-L850-ED2-U
Electronic Driver
Linear LED 5000K
Spacing criterion:
(II) 1.28 x mounting
height, ()1.29 x
mounting height
Lumens: 22339
Input Watts: 149.5W
Effi cacy: 149.4 lm/W
Test Report:
HBLED-LD5-24SE-
W-UNV-L850-ED2-U.
IES
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
Candlepower
Angle Along II 45°Across
7539 7539 7539
7471 7484 7568
7389 7410 7498
7244 7279 7332
7055 7090 7137
6805 6844 6883
6504 6543 6557
6151 6190 6207
5754 5797 5784
5305 5344 5348
4803 4858 4854
4251 4311 4284
3661 3722 3710
3019 3075 3017
2294 2406 2238
1556 1595 547
855 152 133
273 94 105
0 0 0
Coefficients of Utilization
Effective fl oor cavity re ectance 20%
rc 80%70% 50%30% 10
%0
%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
0
1
2
3
4
5
6
7
8
9
10
119 119 119 119 116 116 116 11 6 111 111 111 106 106 106 102 102 102 10 0
109 104 100 97 106 102 98 95 98 95 92 94 92 89 90 88 87 84
99 91 84 79 97 89 83 78 86 80 76 82 78 74 79 76 72 70
90 80 72 65 88 78 71 64 75 69 63 72 67 62 70 65 61 59
82 70 62 55 80 69 61 54 67 59 54 64 58 53 62 57 52 50
76 63 54 47 74 62 53 47 59 52 46 58 51 46 56 50 45 43
70 56 47 41 68 55 47 41 54 46 40 52 45 40 50 44 40 38
65 51 42 36 63 50 42 36 49 41 36 47 40 35 46 40 35 33
60 46 38 32 59 46 38 32 44 37 32 43 36 31 42 36 31 29
56 43 34 29 55 42 34 29 41 34 28 40 33 28 39 33 28 26
53 39 31 26 51 39 31 26 38 31 26 37 30 26 36 30 26 24
Zonal Lumen Summary
Zone Lumens % Fixture
0-30
0-40
0-60
0-90
0-180
5940 26.6
9821 44.0
17795 79.7
22339 100.0
22339 100.0
Luminance Data
Angle
in Deg
Average
0-Deg
cd/sm
Average
45-Deg
cd/sm
Average
90-Deg
cd/sm
45
55
65
75
85
1211 2 11705 11 519
11966 11441 11107
11535 10767 10213
9705 8588 2790
5050 1176 1148
1900
30˚
40˚
50˚
70˚
90˚
20˚
80˚
60˚
3799
5699
7598
10˚
HBLED-LD5-24SE-N-
UNV-L850-ED2-U
Electronic Driver
Linear LED 5000K
Spacing criterion:
(II) 1.27 x mounting
height, () 0.62 x
mounting height
Lumens: 21512
Input Watts: 149.5W
Effi cacy: 143.9 lm/W
Test Report:
HBLED-LD5-24SE-
N-UNV-L850-ED2-U.
IES
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
Candlepower
Angle Along II 45°Across
21788 21788 21788
21529 21799 21422
21269 19695 16860
20835 15546 13351
20231 13010 9948
19464 11063 4401
18563 6969 2062
17510 3265 299
16305 1458 165
14991 242 138
13590 172 55
12018 153 40
10342 11 4 40
8537 95 36
6543 78 45
4359 42 64
2178 38 61
583 23 28
0 0 0
C
oef cients of Utilization
Effective fl oor cavity re ectance 20%
rc 80%70% 50%30% 10%0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
0
1
2
3
4
5
6
7
8
9
10
119 119 119 119 11 6 11 6 11 6 11 6 111 111 111 106 106 106 102 102 102 100
112 109 106 103 110 107 104 101 102 10 0 98 99 97 95 95 94 92 91
105 99 94 90 103 97 93 89 94 90 87 91 88 85 88 86 83 81
98 91 85 80 96 89 84 79 86 82 78 84 80 77 82 78 75 74
92 83 77 72 90 82 76 71 80 74 70 78 73 69 76 72 68 67
87 77 70 65 85 76 69 64 74 68 64 72 67 63 70 66 63 61
82 71 64 59 80 70 64 59 69 63 58 67 62 58 66 61 58 56
77 66 59 54 76 66 59 54 64 58 54 63 58 54 62 57 53 52
73 62 55 50 71 61 55 50 60 54 50 59 54 50 58 53 49 48
69 58 51 47 68 57 51 47 56 51 47 56 50 46 55 50 46 45
65 55 48 44 64 54 48 44 53 47 44 52 47 43 52 47 43 42
Z onal Lumen Summary
Zone Lumens% Fixture
0-30
0-40
0-60
0-90
0-180
11798 54.8
15705 73.0
20174 93.8
21512 100.0
21512100.0
L uminance Data
Angle
in Deg
Average
0-Deg
cd/sm
Average
45-Deg
cd/sm
Average
90-Deg
cd/sm
45
55
65
75
85
34229 529 297
33830 405 104
32614 334 122
27189 228 324
10794 291 302
5561
30˚
40˚
50˚
70˚
90˚
20˚
80˚
60˚
11123
16684
22245
10˚
PHOTOMETRICS
Modular F-Bay Power Supply Option
1. Modular Power Supply Receptacle supplied
mounted into xture Access Plate
2. Modular Power Cord & Plugs in 120, 277, 347,
& 480V congurations for easy plug & power
into existing supply
Modular Motion Sensor Option
suppliedwith Mounting Box and
Modular Power Supply Receptacle
No internal xture
access required for
installation or
disconnecting power
Code Compliance
•UL/cUL Certied for Make/Break
under load (UL2549)
Meets NEC requirements for
ballast disconnect (NEC 410.73G)
Allows for addition of O
ccupancy
Sensor without hard connections
•Receptacles complete with
insulating/dust cap
Cooper
Lighting’s F-Bay Modular Power Supply option is available for use with all F-Bay products. The modular power supply
allows
external xture access for safe and easy servicing. There is no need to remove lamps or reectors to disconnect xture
power
with F-Bay Modular Power Supply. Access to the individual xture’s power supply allows servicing without turning off
all
the xtures, disrupting occupants. F-Bay Modular Power Supply is a time saver in installation – simply plug & power.
12
PS519137EN
10-12-2017
