Specification

WPLD
Low profile LED Wraparound
DESCRIPTION
WPLD series is a versatile LED wraparound series with a streamlined low
profile design that displays uniform, soft light at up to 60% energy savings
over fluorescent light sources. Mounting slots allow for installation directly
into the junction box with 100˚ of rotational freedom. Available features
include suspension mount with optional mounting kit, 93 CRI, dimming to
10%, and efficacy up to 114 lumens per watt.
The WPLD series is an excellent choice for light commercial, retail or
residential applications. Ideal for new construction or simple fluorescent
replacement in basements, kitchens, home office, garages, or bonus rooms.
Construction
Housing consists of cold rolled
steel with emboss for extra rigidity.
Post painted with reflective, baked-
on white enamel using pretreated
metal to ensure maximum
adhesion. High-impact plastic end
caps provide an improved aesthetic
finish.
Shielding
Smooth white lens provides
uniform, glare-free output up to
4600 lumens. Equivalent to a
2-lamp fluorescent T8 wrap.
Installation
Mounting slots for easy wire
connection within junction box.
Suitable for single surface or
suspension mount applications.
Electrical
Long-Life LED and driver
electrical system delivers superior
performance and efficacy up to 115
lm/W. Optional 93 CRI LED’s in
3000K or 4000K for more accurate
color rendering. The WPLD series
offers 10-100% Phase cut or 0-10V
dimming.
Compliance
cULus 1598 listed for damp
locations. Energy Star Certified
for 120V versions. Meets FCC
part 15 class B requirements.
Complies with IESNA LM-79
and LM-80 standards. RoHS
compliant. DesignLights
Consortium® Qualified and
classified for DLC Standard,
refer to www.designlights.org
for details. Suitable for use in
clothes closets when installed
in accordance with the NEC
410.16 spacing requirements.
Warranty
Five-year comprehensive xture
warranty. Projected LED life of
50,000 hours at 70% lumen
output.
SPECIFICATION FEATURES
DIMENSION AND MOUNTING DATA
4'
2-3/32"
[53mm]
42-7/32" [1180mm]
2-3/32"
[53mm]
5-3/16"
[132mm]
PS519208EN
2-6-2018
Metalux AP Series
LOAD DATA
2' 4'
PF 0.99 0.99
THD% 13 14
Weight 3.4 5.8
Low Temp
Start
-20C -20C
Catalog #
Type
Date
Project
Comments
Prepared by
2'
2-3/32"
[53mm]
24-7/16" [621mm]
