Specification Sheet

NY2GC8-228T8A 29 lbs.
NY2GC8-232A 29 lbs.
NY2GC8-428T8A 32 lbs.
NY2GC8-432A 32 lbs.
SHIPPING INFORMATION
Catalog No. Wt.
NY2GC8 T8
Visit our w
eb site at www.cooperlighting.com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone]
ADF111077
ORDERING INFORMATION
SAMPLE NUMBER: NY2GC8-232A-120V-HB81-U
Number of
Lamps
2 or 4 Lamps
(Not included)
Wattage (Length)
28T8=28W T8 (48")
32=32W T8 (48")
(5)
Series
C8=Specification T8 Troffer
Width
2=2' Width
Trim Type
G=Grid/Lay-in (Standard)
(1)
G=Concealed T
G=Slot Grid
F=Flange Trim
Door Frame
Standard=Flat White Steel Door
(Leave Blank)
FA=Flush White Extruded
Aluminum c/w Spring Latch
RA=Regressed White Extruded
Aluminum
FAN=Flush Natural Anodized
Extruded Aluminum
RAN=Regressed Natural
Anodized Extruded Aluminum
FAB=Flush Black Extruded
Aluminum
RAB=Regressed Black Extruded
Aluminum
Shielding
A=#12 Acrylic Pattern
A125=#12 Acrylic Pattern
(.125" Thickness)
A19/156=#19 Acrylic Pattern
(.156" Thickness)
DA=Dropped Dish - Matte
White Acrylic
IMA 48=Injection Molded
Acrylic (.150" Thickness)
PB1S=1/2" x 1/2" x 1/2" Silver
Parabolic Louver (Styrene)
NOTES:
(1)
An EQ Grid Clip is recommended for all 9/16" ceiling systems.
(2)
Products also available in non-US
voltages and frequencies for international markets.
(3)
Not available when specifying emergencies, voltage must
be specific.
(4)
For a complete listing of Fifthlight Technology products and other solutions from Cooper Controls, visit
www.coopercontrol.com.
(5)
Ballast Factor is 0.88 for 4 lamp 32W T8 fixtures.
(6)
0-10V ballast do not include DALI feature.
Please select DALI ballast for use with Fifth Light system.
(7)
Specification grade 0-10V dimming ballast are NEMA
premium and CEE listed. They are compatible with low mercury and energy saving lamps.
(8)
Specification Grade 0-10V
ballast not offered in 3 or 4-lamp versions.
(9)
Standard 0-10V ballast not available for 28W T8 lamps.
(10)
Voltage must be
specified for Standard 0-10V 32W 3 and 4-lamp ballast. 4-lamp ballast versions must be 277V.
Specifications & dimensions subject to change without notice. Consult your Cooper Lighting Representative for
availability and ordering information.
ACCESSORIES
EQ-CLIP-U=T-BAR Safety
Earthquake Clips
(1)
Rating
NY=New York
City Rated
(20 Gauge
Riveted End
Plates)
Ballast Type
EB8
=T8 Electronic Start.
Total Harmonic Distortion < 10%
EB8
/PLUS= T8 Electronic Start.
Total Harmonic Distortion < 10%.
High Ballast Factor > 1.15.
ER8
= T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
High Performance T8 Ballasts
HB8
=T8 Electronic Instant Start.
Total Harmonic Distortion < 10%.
Standard Ballast Factor .86 – .88
HB8
L=T8 Electronic Instant Start.
Total Harmonic Distortion < 10%.
Low Ballast Factor .77 – .82
HB8
N=T8 Electronic Instant Start.
Total Harmonic Distortion < 10%.
Normal Ballast Factor 1.0
HB8
H=T8 Electronic Instant Start.
Total Harmonic Distortion < 10%.
High Ballast Factor 1.15 – 1.20
HR8
T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%.
Standard Ballast Factor .86 – .88
HR8
DIM=T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%.
Step Dimming. Ballast Factor .88
HR8
L=T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%.
Low Ballast Factor .71 – .79
HR8
H=T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%.
High Ballast Factor 1.15 – 1.20
0-10V Dimming Ballasts
(6)
5LTV8 =T8 0-10V Program Rapid Start.
Total Harmonic Distortion < 10%.
Ballast Factor 0.87
(9), (10)
5LTVS8 =T8 0-10V Spec Grade Program
Rapid Start. Total Harmonic
Distortion < 10%.
Ballast Factor 0.87
(7), (8)
Fifth Light DALI Ballasts
(4)
5LT8 =T8 DALI Program Rapid Start.
Total Harmonic Distortion < 10%.
Ballast Factor 1.0
Options
FR=Fire Rated Label
MEP=Modified End Plates
PAF=Painted After
Fabrication
Voltage
(2)
120V=120 Volt
277V=277 Volt
347V=347 Volt
UNV=Universal Voltage 120-277
(3)
Options
GL=Single Element Fuse
GM=Double Element Fuse
Lamps=Lamps Installed
Flex=Flex Installed
EL=Emergency Installed
Packaging
U=Unit Pack
PAL=Job Pack, out of carton
PALC=Job Pack, in carton
Number of Ballasts
1=1 Ballast
2=2 Ballasts
3=3 Ballasts
