Parts List

WX 2000
Позиция Количество Номер для заказа Описание PG
1 1 314000280 Handle cpl. 25
2 1 343376440 Push button 13
3 1 342001730 Pressure spring 11
4 1 341003970 Guide bush 15
5 1 316031720 Gear housing cpl. 34
6 1 341513810 Thrust bolt 12
7 1 341100660 Self locking nut 14
8 1 316025290 Bevel gear 35
9 1 341011510 Spacer ring 17
10 1 143192440 Felt ring 14
11 1 339070080 Cover washer 12
12 1 143115230 Ball bearing, 12x37x12 19
13 1 339007280 Fixed bearing cover 14
14 1 316094250 Armature compl. 40
15 1 143113400 Ball bearing, 8x22x7 22
16 1 344094080 Rubber bearing 12
17 1 339150950 Baffle 14
18 2 141121680 Self-tap. fill. h. screw 11
19 1 311012600 Field coil compl. 36
20 4 141119370 Self-tap. fill. h. screw 11
21 1 141122020 Fillister head screw 11
22 1 141124800 Fillister head screw 11
23 1 339060140 Sealing ring 12
24 1 316047470 Gear flange compl.,D 230 28
25 4 141121640 Fill. head screw(DIN 7985) 11
26 1 341604160 Spindle 23
27 1 341106900 Flange nut 20
28 1 341031160 Clamping flange 22
29 1 316045000 Wheel guard compl.,D 230 27
30 2 341702050 Screw 11
31 2 343376430 Cover 12
32 1 316047480 Carbon brush set 22
33 2 343000770 Brush guide 18
34 4 141116020 Self-tap fill h screw 12
35 1 343398260 Handle (upper+under part) 22
36 1 316045410 Switch compl.,230V 34
37 1 339127730 Cable clip 11
38 1 141116800 Self-tap. fill. h. screw 11
39 1 344094550 Cable sleeve 13
40 1 344487800 Cable with plug 30
41 1 338117340 Indication label 11
2/4
