Parts List

WEA 14-150 Plus
Позиция Количество Номер для заказа Описание PG
1 1 341102140 Hexagon nut w.recess 11
2 1 316052140 Bevel gear and bevel gear 31
3 1 339006390 Washer,7,05x19,5x0,2 11
4 1 143115180 Ball bearing,8x22x7 17
5 1 339132280 Washer 11
6 1 316041450 Fan w. prot. Grid 17
7 1 310009170 Armature compl.,230V 39
8 1 143115170 Ball bearing,6x19x6 16
9 1 344097870 Rubber bushing 11
10 1 343393650 Push button red 11
11 1 342003390 Pressure spring 11
12 1 316041620 Gear housing compl. 29
13 1 143193650 O-ring 11
14 1 341515280 Bolt 11
15 4 141123660 Fillister head screw 11
16 4 141116020 Self-tap fill h screw 12
17 1 316041650 Friction washer cpl. 23
19 2 339011570 Gasket 11
20 1 316041720 Flange w.clamping lever cpl. 29
21 1 341161070 Spindle shaft 26
22 1 316043580 Intermediate gear 38
23 1 141151120 Washer 10,2 X 14,8X 0,2 11
24 1 141152300 Washer 10,2 X 14,8X 0,1 12
25 1 141155550 Washer 10,2 X 14,8X 1,0 11
26 1 342022040 Spring clip 11
27 1 341070440 Lever 14
28 1 141181810 Circlip 11
29 1 342050840 Compression Spring 11
30 1 339203020 Wheel guard,D150 23
31 1 341147870 Autobalancer 33
32 1 316023660 Clamping nut compl.,M14 25
33 1 314000970 Anti-vibration handle,M 8 24
34 1 339151040 Baffle 12
35 1 311010750 Field coil assembly w.field coil,230V 37
36 1 315013230 Motor housing 20
37 2 316045170 Brush holder compl. cut out,230V 21
38 1 316042070 Carbon brush Set,230V 21
39 1 343393530 Switch rod 11
40 1 343392980 Switch slide 11
41 1 343393460 Housing cover 17
42 1 338122910 M-Label 08 TR 49-52x22 WEA 14-150 Plus 15
