Use And Care Manual
10
English
SPECIFICATIONS
Model NT50AE2 (S) NT32AE2 (S)
Operating pressure 70 – 120 psi (4.9 – 8.3 bar, 5 – 8.5 kgf/cm
2
)
Dimensions
Length × Height × Width
10" × 9-3/16" × 2-3/8"
(254 mm × 233 mm × 60 mm)
10" × 7-3/4" × 2-3/8"
(254 mm × 197 mm × 60 mm)
Weight 2.2 lbs. (1.0 kg) 2.0 lbs. (.9 kg)
Nail capacity 100 Nails
Air consumption
.025 ft
3
/cycle at 100 psi
(.73 ltr/cycle at 6.9 bar)
(.73 ltr/cycle at 7 kgf/cm
2
)
NAIL SELECTION
WARNING
●
Be sure to use only the genuine metabo HPT nails for the NT50AE2 (S), NT32AE2 (S). The use of any other
nails can result in tool malfunction and/or nail breakdown, leading to serious injuries.
Only nails shown in the Table below can be driven with this Nailer.
Dimensions of nails
18 Gauge brad nails
Min. Max.
NT50AE2 (S) • NT32AE2 (S) NT50AE2 (S) NT32AE2 (S)
.075" (1.9 mm)
5/8" (16 mm)
.043" (1.1 mm)
.049"
(1.25 mm)
.039"
(1 mm)
2" (50 mm)
1-1/4" (32 mm)
