ACTIVATION AND CONFIGURATION
1-ACTIVATION PORT OPTICS METER
Use the right button to move to the D screen of the display.
Press and hold the left button for 5 seconds until the icon appears.
2 - COMPILATION OF CONFIGURATION FIELDS
Optionally, the utility that installs the meter, has the ability to set the following parameters:
- Time zone
- Date of commencement of daylight saving time
- Date of end of daylight saving time
- Deviation applied to daylight saving time
- Enabling daylight saving time
- Date/Time
3- STATUS CONFIGURATION
Once you have entered the information listed in the previous point, you can confirm what
you have entered by means of a special command.
Confirmation of the configuration data generates an automatic change in status from NOT
CONFIGURED to NORMAL.
4- AFFILIATION
the Operation through a special command will send a dedicated data packet (data packet
pre-set in the software) to the concentrator, this will send the response to the meter, which
once received will be affiliated.
5- DEACTIVATION OF THE OPTICAL PORT
The optical port is automatically deactivated.
