Specifications

4
Table 1 - Performance and Dimensional Data - Separated Combustion Tubular Blower Unit Heater
Unit Capacity (MBH) 100 125 150 175 200 250 300 350 400
PERFORMANCE DATA†
Input - BTU/Hr. 100,000 125,000 150,000 175,000 200,000 250,000 300,000 350,000 400,000
(kW) (29.3) (36.6) (44.0) (51.3) (58.6) (73.3) (87.9) (102.6) (117.2)
Output - BTU/Hr. 83,000 103,750 124,500 145,250 166,000 207,500 246,000 290,500 332,000
(kW) (24.3) (30.4) (36.5) (42.6) (48.6) (60.8) (72.1) (85.1) (97.3)
Thermal Effi ciency - % 83 83 83 83 83 83 82 83 83
Free Air Delivery - CFM 1,181 1,476 1,771 2,067 2,362 2,953 3,501 4,134 4,724
(cu. m/s) (0.557) (0.697) (0.836) (0.976) (1.115) (1.394) (1.652) (1.951) (2.230)
Air Temperature Rise - Deg. F 65
(Deg. C) (36)
Outlet Velocity - FPM 370 463 555 395.0 451.0 564.0 422 498 570
(m/s) (1.879) (2.351) (2.819) (2.006) (2.291) (2.864) (2.143) (2.529) (2.895)
Full Load Amps at 115V 7.3 9.4 9.4 14.2 14.2 15.6 15.6 20.8 20.8
Maximum Circuit Ampacity 8.6 11.2 11.2 17.1 17.1 18.9 18.9 25.4 25.4
MOTOR DATA:
Motor HP 1/4 1/2 3/4 1 1-1/2
Motor kW 0.19 0.37 0.56 0.75 1.11
Motor Type** SPH SPH SPH Cap. Start Cap. Start
RPM 1,725 1,725 1,725 1,725 1,725
Amps @ 115V 5.1 7.2 11.6 13.0 18.2
DIMENSIONAL DATA - inches (mm)
"A" Height to Top of Flue 33-3/4 34
(857) (864)
"B" Jacket Width of Unit 20-3/4 32-3/4 50-3/4
(527) (832) (1289)
"C" Width to Centerline Flue 13-3/8 19-3/8 28-3/8
(340) (492) (721)
"D" Depth to Front Hanger
21
(533)
"E" Hanging Distance Width 18-5/8 30-5/8 48-5/8
(473) (778) (1235)
"F" Hanging Distance Depth 19 19-1/2 32-3/4 23-1/2 32-3/4
(483) (495) (832) (597) (832)
"G" Discharge Opening Width 18-3/4 30-3/4 48-3/4
(476) (781) (1238)
"H" Depth to Centerline Flue 4-3/4 5-1/8
(121) (130)
"M" Overall Unit Width 25-1/4 37-1/4 55-1/4
(641) (946) (1403)
"P" Overall Unit Depth 49-3/4 49-3/8 56-1/8 53-3/8 56-1/8
(1264) (1254) (1426) (1356) (1426)
*Flue Size Diameter - in 5 6
(mm) (127) (152)
Gas Inlet, Natural Gas - in 1/2 3/4
Gas Inlet, LP Gas - in 1/2 1/2 OR 3/4
Approximate Unit Weight - lb 173 177 204 248 267 292 374 394 433
(kg) (78) (80) (92) (112) (121) (132) (170) (179) (196)
Approximate Ship Weight - lb 258 263 291 384 403 428 524 551 599
(kg) (117) (119) (132) (174) (183) (194) (238) (250) (272)
† Ratings shown are for unit installations at elevations between 0 and 2,000 ft (0 to 610m). For unit installations in U.S.A. above 2,000 ft. (610m), the unit input must be fi eld derated 4% for each
1,000 ft. (305m) above sea level; refer to local codes, or in absence of local codes, refer to the latest edition of the National Fuel Gas Code, ANSI Standard Z223.1 (N.F.P.A. No. 54).
For installations in Canada, any reference to deration at altitudes in excess of 2,000 ft. (610m) are to be ignored. At altitudes of 2,000 ft. to 4,500 ft. (610 to 1372m), the unit must be fi eld derated
to 90% of the normal altitude rating, and be so marked in accordance with the ETL certifi cation. See Table 8A for fi eld deration information.
* Flue collar is factory supplied with unit; to be fi eld installed per included instructions.
** LEGEND: SPH = SPLIT PHASE CAP. START = CAPACITOR START
