1.4 Identifying the Parts of the Camera
Pin Denition Description
1 RJ45
Use this connector to make a 10BaseT/100Base-TX link
between the camera and network devices like hubs, switches
or routers.
With connecting to a POE+ compliant PSE, the camera can be
powered via this RJ-45 cable.
2 Power Input (Black/White)
Wire this terminal block to an AC power supply.
If you are to use power via the Fast Ethernet connection, this
terminal block is not used.
3 Reset (Orange/White)
Wire the terminal block with an on/off switch or just have the
two conducts shorted to restart the system
4 Audio-in (Black/White)
Connect to an external microphone to record audio around
the camera site.
5
Alarm-out Open (Light
Green)
Wired to send signals to external devices for alarm purposes.
Alarm-out Com (Black)
Alarm-out Close (Purple)
6
Alarm-in 5 (Blue)
Wired to receive alarm signals triggered by external devices.Alarm-in 6 (Green)
Alarm-in GND (White)
7
Alarm-in 1 (Red)
Wired to receive alarm signals triggered by external devices.
Alarm-in 2 (Brown)
8
Alarm-in 3 (Yellow)
Wired to receive alarm signals triggered by external devices.
Alarm-in 4 (Orange)
9 Default (Pink/Gray)
Wire the terminal block with an on/off switch or just have the
two conducts shorted for at least ve seconds to load factory
default.
