1.5 Specications
Video
Sensor Type 1/2.8" image sensor(CMOS)
Active Pixels 1920x1080 (HxV)
Compression H.264 / MJPEG
Streaming Dual streaming
Resolution 1080P, 720P, 480P, VGA, QVGA, CIF
Max. Frame Rate 2MP 16:9 (1920x1080) at 30 fps (NTSC/
PAL)
Day/Night Mechanical (ICR) D/N control
Day/Night Mode Auto, Day, Night
Shutter Time 1/10000s to 1s selectable (60Hz/50Hz)
Minimum Illumination Color 0.4 Lux, B/W 0.08 Lux @30IRE
Color 1.7 Lux, B/W 0.3 Lux @50IRE
(Shutter speed: 1/30 sec)
Bit Rate Control Primary stream bit rate control: CBR/
VBR
Lens
Type, Focal Length, F-number Built-in Mechanical IR Cut Filter varifocal
lens, f=4.7~94mm, F1.6~3.5 (Mega pixel
lens)
View Angle H:55.4°(wide), 2.9°(tele) Full HD mode
Zoom Limit Up to 240X (Optical 20X, Digital 12X)
IRIS Control Auto
P/T Operation
Pan Range 360° continuous
Tilt Range 92°
Manual Pan Speed 0.1~120°/s, 0.1°/s: max dig.optical
zoom
Manual Tilt Speed 0.1~ 90°/s, 0.1°/s: max dig.optical zoom
Preset Speed Pan:430°/s, Tilt:200°/s
Proportional P/T Yes
Programmable Presets 128
Auto Patrol Group 4
Stop Time 3, 5, 7, 15, 30, 60 sec
Scan function Auto, Random, Frame
Recover time limit OFF, 1~120 min
Recover Time Limit OFF, 1 to 120 minutes
Audio
Audio Communication One-Way audio
Compression G711-Alaw, G711-Ulaw, PCM, 8kHz
Audio In/Out External microphone
Image Enhancement
Image Settings Exposure Mode: Auto/shutter priority
White Balance: Auto/ATW/Indoor/
Outdoor/One-Push
Backlight Compensation: On/Off
Sharpness: 15 level sensitivity
WDR Yes
DNR Yes
Privacy Zone Yes; customized threshold privacy zone
Image Orientation Mirror, Flip
Frequency Control 50Hz, 60Hz
Intelligent Video & Event Management
Motion Detection Yes; 3 level sensitivity
Others Snapshot, Freeze Activity
Events Motion detection, external alarm
Event Actions File upload via FTP, SMTP and SD Card,
Notication via email
Store Category Alarm / Event / Schedule recording
Stores snapshots
Local Storage
Memory Card Slot Micro SD Card up to 32 GB
Memory Card Overwrite Yes
Network
Protocol IPv4, HTTP, TCP, RTSP/RTCP/RTP, ICMP,
UDP, IGMP, DNS, DHCP, ARP, NTP ,UPnP,
DDNS, SMTP
Ethernet 1 x 10/100 base-T Ethernet connection
for LAN/WAN, RJ45
PoE PoE+(IEEE 802.3at)
Browser IE Browser 8.0 , 9.0
Security Password protection
I/O Connector
Power 2-pin Terminal Block
Alarm In/Out Terminal Block 6 in / 1 out
Network RJ-45 for Ethernet 10BaseT/100BaseTX
Audio In/Out Terminal Block 1 in / 0 out
Reset 2-pin Terminal Block
Power
Power Requirement AC24V ± 10% / PoE+(IEEE 802.3at)
Power Consumption (Max.) 55W
Mechanical
Dimensions(ΦxH) 216.14mm X 360.19mm (8.51" X 14.18")
Weight 3800g (8.14lb)
Protection IP67, IK10
Battery Backed-up Real-time
Clock
Internal RTC
Environmental
Operating Temperature -40° to 50°C(AC24V); -10° to
50°C(PoE+)/AC24V
Operating Humidity 20~90%RH
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Regulation
EMI FCC Part 15 Class A, CISPR 22 Class A,
EN 55022 Class A, EN 61000-3-2, EN
61000-3-3
EMS EN 50130-4, EN 61000-4-2, EN 61000-
4-3, EN 61000-4-4, EN 61000-4-5, EN
61000-4-6, EN61000-4-11
