Installation Guide

66 Meru Access Point and Radio Switch Installation Guide © 2007 Meru Networks, Inc.
Canada. Industry Canada (IC)
Access Points have been designed to operate with the antennas listed below.
Antennas not included in this list are strictly prohibited for use with these devices.
The required antenna impedance is 50 ohms.
Caution!
Exposure to Radio Frequency Radiation.
The installer of this radio equipment must ensure that the antenna is
located or pointed such that it does not emit an RF field in excess of
Health Canada limits for the general population; consult Safety Code 6,
obtainable from Health Canada’s website http://www.hc-sc.gc.ca/rpb.
Note:
Meru Access Points
These devices are restricted to indoor use because they operate in the
5.15 to 5.25 GHz frequency range. Industry Canada requires such products
to be used indoors for the frequency range 5.15 GHz to 5.25 GHz to reduce
the potential for harmful interference to co-channel Mobile Satellite sys-
tems.
High-power radars are allocated as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar stations can cause interference
with or damage to these devices, or both.
AP Model Antenna Type Gain (2.4 GHz) Gain (5 GHz)
AP200
Dual-Band Omni-Directional
SAA04-220050
2 dBi 3 dBi
AP200
Dual-Band Omni-Directional
TWX-614XRSXX
4 dBi 5 dBi
AP150
Dual-Band Omni-Directional
MMO224580608
6 dBi
8 dBi
AP150
Single-Band Omni-Directional
SAA04-050280
8 dBi
AP150 Panel
MP24013 XFPTNF
13 dBi
