Checking LED Activity
© 2007 Meru Networks, Inc. Installing the RS4000 29
Table 3: RS4000 LED Descriptions
LED Function
Power
The Power status LED status is as follows:
z off—power is off
z solid red—when power is applied, system initializes for 40 sec-
onds and then the LED turns amber; after discovering the con-
troller the LED turns green. Otherwise, the system is in an
abnormal state (notify Customer Support).
z solid amber—at any time, if this LED state persists longer than 40
seconds, notify Customer Support
z solid green—system is fully operational
Radio I
The Radio I LED is lit when radio packets are being transmitted and
when the radio is beaconing.
Radio II
The Radio II LED is lit when radio packets are being transmitted and
when the radio is beaconing.
Ethernet
The Ethernet LED status is as follows:
z off—no link
z solid green—100Mbps connection
z blinking green—transmit or receive activity at 100Mbps
z solid amber—10Mbps connection
z blinking amber—transmit or receive activity at 10Mbps
