E6 SERVICE MANUAL REV C 06/12
43
SPARE PARTS
Parts list
Item# SparePart# Description
1 333000 MAGNETRON,TOSHIBA
2 333002 TRANSFORMER,HV
3 333013 RESISTANGASKET
4 N/A OMITTED–REPLACEDBYITEM#11
5 333034 HI‐LIMIT,MAGNETRON
6 333036 FANGUARD
7 333044 SPEEDCONTROLSIEMENS
8 333047 CAPACITOR‐HV.88uF
9 333055 CATALYST,6.4~X2.5~X1.0~
10 333056 COOKPLATE,603OVEN
11 333058 FILTERHOUSINGASSEMBLY
12 333070 BLOWERASSEMBLY
13 333075 RFIFILTER
14 333076 FUSE‐MAINCIRCUIT
15 333078 DIODEBOARDASSEMBLY
16 333080 STIRRERMOTOR,SAIABURG
17 333084 BUDGETTOUCHSCREEN,QTS
18 333085 TRANSFORMER,LV
19 333087 SWITCHON/OFF
20 333094 CORDSET,30A6‐30PPLUG(NOTSHOWN)
21 333096 CLAMP,CAPACITOR
22 333097 DOORSWITCHSPACER,603
23 333098 GEAR,STIRRER
24 333099 GEAR,STIRRERMOTOR
25 333100 DOORGASKET
26 333107 HEATINGELEM‐RADWATLOW
27 333110 CABINETFAN,SUNON
28 333111 FUSEBK/MDA‐20‐RT‐LAG
29 333112 RIGHTDOORHINGE
30 333113 LEFTDOORHINGE
31 333121 CUT‐OFFBULBMOUNT(NOTSHOWN)
32 333138 SEALANTRTV106TUBE(NOTSHOWN)
33 333166 STIRRERANTENNA
34 333189 TOUCHSCREENOVERLAY
35 333196 CAVITYTHERMOCOUPLEASSY
36 333205 HARMONISEDSPEAKER
37 333206 BorosilicatePartition
38 333210 MERRYCHEFBADGEGUIDE
39 333212 USBADAPTERMODULE
40 369125 TERMINALBLOCK2POLE
41 333215 SCROLLHOUSING‐CW
42 333216 TOPHEATER,RADIANTOVEN
43 333217 LOCTITE2620HITEMP(NOTSHOWN)
