Figure 90 Configuration Import Settings
The procedure to import a file to the Base Station:
1. Select the filename to import into the running configuration from the drop-down menu of the
Import Filename.
2. If the User enables the Overwrite field, then this will replace the existing CPE configuration data
with the imported data. This will only work with files created with the export CPE option. Trying
to load other files with the overwrite option set will result in an error message.
3. If the User does not enable the Overwrite field, then the imported data will be merged with the
existing configuration.
4. The User must then press the Perform Command Menu Option.
The Import command can take several minutes to complete. Please wait until this process
is completed before going on to make any other configuration changes.
At the Main Web GUI Interface Screen select the Configuration Tab, then configuration Main Menu
Option and then the write Main Menu Sub-Element. This will display window to write a configuration file
(Figure 91). The write procedure will copy the running configuration to startup. The new startup
configuration will be effective at the next reboot of the Base Station.
Please note that changes will not be persistent and survive a restart unless the write
command is issued after the changes are made.
