Figure 89 Configuration Export Settings
1. Select the CLI export filter from the drop-down menu of the CLI Export Filter. The options are:
a. All. This will export the entire configuration database.
b. BS-Configuration. Base Station configuration database only. This excludes CPE and
Service-profiles.
c. CPE. This will export the Subscriber CPE provisioning database only.
d. Service-Profile. This will export the Service Profile database only.
2. Enter the destination filename to export the database in the Filename field.
3. The User must then press the Perform Command Menu Option.
4. The relevant file will now be created, and the results of this action will be displayed.
At the Main Web GUI Interface Screen select the Configuration Tab, then configuration Main Menu
Option and then the import Main Menu Sub-Element. This will display window to import a configuration
file (Figure 90). The import option will import a configuration into the running configuration.
Overwriting the configuration file can have serious consequences. The User must proceed
with care.
