3. Enable the Force field if the User wants to overwrite an existing file on the Base Station.
4. The User must then press the Perform Command Menu Option.
5. The relevant file will now be copied, and the results of this action will be displayed as below.
Figure 86 Configuration Copy Successful
At the Main Web GUI Interface Screen select the Configuration Tab, then configuration Main Menu
Option and then the move Main Menu Sub-Element. This will display window to move or rename a
configuration file (Figure 87).
Figure 87 Configuration Move Settings
The procedure to rename a file is:
1. Select the file to be renamed from the drop-down menu of the Existing File Name field.
2. Enter the new file name in the New File Name field.
3. The User must then press the Perform Command Menu Option.
4. The relevant file will now be renamed, and the results of this action will be displayed.
