Figure 76 GPS Settings and Configuration
The GPS Settings display is split into one main group sections. An indication as to whether there are any
User configurable parameters included in the group is provided. If the User wants to configure any of the
parameters, then they must enter the Edit Mode (select Edit Private or Edit Exclusive) and edit as
necessary. The methods to Edit the parameters will be offered via an enabling of a check box or editing
of a notepad icon.
A GPS antenna MUST be connected to the Base Station before setting GPS Admin Status
to “Enabled”
The GPS Settings and Status window contains:
GPS Admin Status. This is an indication of the GPS Admin Status. The options are enabled and disabled
with disabled as the default.
• Sync Recovery Timeout Interval. The Base Station has a Sync Recovery feature, whereby the
Base Station Radio is automatically reset if GPS sync is lost for more than a specified timeout
period. The timeout period (in seconds) is specified via the Sync Recovery Timeout Interval
parameter. The default value is 1800 seconds.
• Latitude (degrees). This is the latitude location of the GPS receiver. This is not a User
configurable parameter.
• Longitude (degrees). This is the longitude location of the GPS receiver. This is not a User
configurable parameter.
• State. This is an indication of the state of the GPS receiver. This is not a User configurable
parameter.
