Sector Radio Center Frequency
Center frequency in kHz
Sector Channel Bandwidth
3.5MHz, 5MHz, 7MHz, or 10 MHz (default)
Sector Radio Power Output
Preamble power output value per antenna (includes 3 dB
preamble). Default: 23 dBm.
Operations under FCC Part 96:
Power setting shall not exceed:
3.5 MHz: 31 dBm
5 MHz: 32 dBm
7 MHz: 32 dBm
10 MHz: 33 dBm
Sector Radio Antenna Gain
Antenna gain (dBi)
Sector Radio Cable Loss
Estimated external cable loss (dB)
Sector Antenna TX Mode
MIMO-A (default) or MIMO-AB
Sector DL:UL Frame Ratio
26:21, 29:18, 32:15, 35:12 (default) in 5MHz and 10MHz
23:9, 21:12, 17:15 in 3.5 and 7MHz
Table 11 Base Station Sector Configuration Data
The Web GUI Interface will be used to configure the parameters that are required in Table 11. The starting
point for all configurations is the Main Web GUI Interface Screen. The relevant parameters are distributed
across several different menu options and hence screens and windows. Each of these options will be
discussed in detail.
After making the various configuration changes, the User will need to “commit” and
“save” the changes.
3.5.3.1 Sector, General Settings
At the Main Web GUI Interface Screen select the Configuration Tab, select sector Main Menu
Option and then general Main Menu Sub-Element. This will display the Sector Settings window.
There are two basic groups to this Sector option. These are:
• Sector Advanced Settings (configured)
• Sector Provisioning (configured)
The User now has to navigate to the next level, therefore at the Main Web GUI Interface
Screen select the Configuration Tab, select sector Main Menu Option, general Main Menu Sub-Element
and then 1, this will display the key settings window. There are three distinct groups to this window
(Figure 38).
