Quick Start Guide

Designed for Operators, by Operators
30 | P a g e
The "Save Procedure" is to ensure that the running configuration is saved is:
1. At the Main Web GUI Interface Screen, select the Configuration Tab, select the configuration
Main Menu Option then the write Main Menu Sub-Element. The User will have to click on the
Perform Command Menu Option to copy the running configuration to the startup as below.
Figure 19 Writing Running Configuration to Startup
2. A pop-up window indicating that the write was successful will be displayed.
Note: Several configuration changes require that the Sector be rebooted. The only
parameter requiring a complete Base Station reboot is enabling or disabling the ASN
Gateway settings.
The procedure to reboot a Base Station is as follows:
1. At the Main Web GUI Interface Screen, select the Configuration Tab, select the administration
Main Menu option and then reboot Main Menu Sub-Element. The User will have to click on the
Perform Command Menu Option to reboot the entire Base Station (Figure 20).
