2. Open a terminal emulation program on the computer. Suitable programs are PuTTY or
HyperTerminal (Figure 4).
Create a new connection with the serial port settings as outlined in Table 9.
Serial Console Port Settings
Serial Line
COM1
Speed (Baud Rates)
38400
Data bits
8
Stop Bits
1
Parity
None
Flow Control
None
Table 9 Console Port Settings
Figure 4 PuTTY Serial Port Configuration Window
