Quick Start Guide

Designed for Operators, by Operators
179 | P a g e
Figure 181 Spectrum Inquiry Screen
Once a grant has been received an updated SAS status will be displayed (Figure 183). The Quantum 6636
should now receive instructions from the Domain Proxy for transmit. If the requested frequency is not
available an error will be displayed.
Figure 182 SAS Status Update
4.3.3 CPIs (Certified Professional Installers)
The CBRS band provides for a sophisticated multi-tier shared spectrum with protected incumbents.
Pursuant to the FCC, the majority of CBRS radio transceivers or Citizen’s Broadband Service Devices
(CBSDs) must be installed by a CPI in order to lawfully operate within the designated spectrum of CBRS.
In order to meet the FCC Part 96 rules, CPIs must be trained and currently certified. The WInnForum’s the
CPI Accreditation Standard provides a working outline of how training programs for CPI will be achieved
as well as what CBSDs need certification, CPI responsibilities, and more. CPIs using the Mercury Networks
Domain Proxy can be managed through the CPIs menu.
4.3.3.1 Adding a New CPI
In the CPIs menu, a new CPI can be added by selecting ‘Create’ in the upper right-hand corner (Figure
184).
