4.3.2.3 Adding a Device
Clicking the blue “+” button on the devices sub-menu opens the New Device screen (Figure 178). The
Quantum 6636 will need to have a management IP configured before you can add the device to the
Domain Proxy. Once the management IP address is known, add it under the IP field, followed by the
SNMP Community (by default this is private for most Quantum 6636 Base Stations). Once the IP and the
SNMP community have been entered, select Query.
Figure 177 New Device
The User will be presented with a summary screen displaying all parameters automatically imported to
the Domain Proxy (Figure 179 and 180). The following remaining parameters will need to be provided
before the Quantum 6636 can be successfully added and registered to the Domain Proxy:
• Height (meters) – Height Above Average Terrain – The FCC currently provides a HAAT calculator
to assist users with obtaining and entering this data (https://www.fcc.gov/media/radio/haat-
calculator).
