A Certified Professional Installer (CPI) is required for activation of any CBSD for use with a
SAS. The Quantum 6636, as with any CBSD, will not transmit until all necessary
configuration parameters have been input into the Domain Proxy, and a CPI has signed off
on the physical installation of the CBSD.
The Mercury Networks Domain Proxy is designed to act as a management platform for the Quantum 6636
product line, as well as a bridge for multiple Base Stations to communicate with a SAS. It possesses an
intuitive, web-based GUI that will assist with commands issued by the SAS.
4.3.1 Accessing the Mercury Networks Domain Proxy
The Mercury Networks Domain Proxy can be accessed through a web browser by pointing your browser
at the URL established for the Domain Proxy by the Mercury Networks support team. Once the page loads
the User is presented with a login screen. Enter your E-mail Address and Password to get started (Figure
172).
Figure 172 Domain Proxy Login
Once login credentials are successfully entered, the User is presented with a welcome screen, and tabs
across the top of the screen for navigation (Figure 173).
The navigation tabs include:
• Devices – Displays a list of all CBSDs entered into the Domain Proxy
• CPIs – Displays a list of all Certified Professional Installers capable of signing-off on a CBSD
installation. (Note: certificates for CPIs can be managed in the Domain Proxy, this will be covered
later in this section).
