4.3.1 Mercury Networks 3.3-3.8GHz 2-Port Antenna (098-00459-035)
The Mercury Networks 3.5GHz 2-Port Antenna (098-00459-0035) allows for a sectorized, cross polarized
deployment. For operations under Part 96 that involve a single Quantum 6636 deployment, or
“OmniWave” deployment, the following antenna array and configuration should be used to prevent
overlap and interference. Antenna specifications can be found on the following table:
2-port antenna installation should be sectorized, cross polarized, and arranged so that the
3dB band does not overlap each other.
