4. All Quantum 6636 installations will need to be signed by a Certified Professional Installer (CPI)
with a valid certificate loaded into the Mercury Networks Domain Proxy. To learn more about the
Mercury Networks Domain Proxy, see section 4.3 of this guide.
4.2 Base Station Configuration for use with CBRS and the Mercury Networks Domain
Proxy
The following section will outline the basic configuration parameters that need to be established with
the Quantum 6636 product prior to use with the Mercury Networks Domain Proxy. There are two
methods for managing/configuring a Base Station:
1. Command Line Interface (CLI)
2. Graphical User Interface (GUI) Web Interface
All configuration parameters are available through CLI. The CLI is recommended for configuring a Base
Station for use in the CBRS band and with the Mercury Networks Domain Proxy. The CLI is accessible via
the Base Station Console Interface using an appropriate terminal emulator, or via a Base Station ETH-1
port using either SSH or Telnet (Telnet is disabled by default). Refer to section 3 – Quick Start Guide for
additional information regarding initial configuration, and a full list of configurable parameters.
The following commands assume you have read through section 3 and are prepared to use the CLI for
issuing configuration commands to the Base Station. Items you will need to know prior to configuration
are:
• System IP address
• Sector IP address
• Management VLAN
• Antenna gain
• Antenna beadwidth
• Antenna downtilt
• Cable loss
• Host Name
• BSID
• Time Zone
• NTP Server
Enter configuration mode and issue the following commands via CLI to configure the Quantum 6636:
1. configure
2. Connect to the Base Station via ETH-1.
a. Default Base Station Management IP address (Host Name): 192.168.1.10
b. Default credentials are:
admin
admin123
3. Gather the needed files for the software upgrade (contact [e-mail])
4. Perform the necessary software upgrade to both banks A and B
5. Run commands
