160 | P a g e
Figure 168 SNMP Notify Configuration
Name
Description
Field Example
SNMP Notify Name
A unique identifier used to index this table.
1-32 chars
SNMP Notify Tag
A tag value used to reference one or more entries in
snmpTargetAddrTable.
Example: “std_trap”
SNMP Notify Type
Selects the type of notification to be generated for
the entries in the snmpTargetAddrTable referenced
by snmpNotifyTag:
trap(1) - Generates an SNMPv2c Trap PDU
inform(2) - Generates an InformRequest PDU
Example: trap
SNMP Notify Storage Type
String name assigned to the Base Station.
The default value is
nonVolatile.
Table 12 SNMP Notification Table
