Quick Start Guide

Designed for Operators, by Operators
16 | P a g e
Surge Protection
UL497B
Lightning Protection
Min 10kA IEC 6100-4-5 (optional via external kit)
Weatherproofing
IEC IP67
Wind Loading
160Km/hr operation, 200Km/hr survival
Safety and IEC IP
EN 300 019-2-2, GR487, IEC 60529
Vibration and Dust
ETSI EN 300 019-1-4 Class 4.1E
Table 7 Environmental and Mechanical Specifications
For temperatures above +45 degrees C in direct sunlight it is necessary to deploy the Base Station
with the available solar shield, shown in Figure 3. Again, details can be found in the Mercury Quantum
6600 Base Station Installation Guide.
Figure 3 Quantum 6600 with Available Solar Shield
