At the Main Web GUI Interface Screen select the Configuration Tab and then select the logging Main
Menu Option and then the local Main Menu Sub-Element. The User is now presented with a window that
displays the local Log Server Settings. This only one distinct group to this window (Figure 157). The User
can select to view the relevant details.
• Default Local Log Server Settings. The User can view and hence configure the default minimum
severity log level for the local internal log server. This will apply to all local servers except those
which have been configured in the logging local override configuration. The User must be in Edit
Mode to configure. To define the default level there are one of nine available options to select.
These are:
o none
o debug
o info
o notice
o warning
o error
o critical
o alert
o emergency
Figure 157 Logging Local Information
At the Main Web GUI Interface Screen select the Configuration Tab, then select the logging Main Menu
option, then the local Main Menu Sub-Element and then override. The User can now is now presented
with an option to increase or decrease the internal sys log per daemon/application which are internal to
the Base Station (Figure 158). The User must be in Edit mode to configure.
