Quick Start Guide

Designed for Operators, by Operators
15 | P a g e
Peak Throughput
Aggregate: Up to 58Mbps (35:12 Ratio)
DL: Up to 43Mbps (35:12 Ratio)
UL: Up to 8Mbps (26:21 Ratio)
QoS
BE, UGS, eRTPs, nRTPs, RTPs
Convergence Sub-Layer
IP-CS, Eth-CS, IPv4, IPv6 Pass-Through
Security
Security AES-128, EAP-TLS, EAP-TTLS, PKMv2
Management
PureView NMS / EMS, Remote CLI, Web Interface,
SNMP v2c, SNMPv3
Core Network Interface
R6 (NWG 1.2.2, NWG 1.3.1), Radius
Table 6 Performance Characteristics
2.3.4 Electro-Mechanical and Environmental Specifications
All Mercury Quantum Family Base Stations consist of a single, all-in-one, fully weatherproof unit that
may be installed entirely outdoors or indoors, as dictated by each deployment. Please refer to the
Mercury Quantum Base Station Installation Guide for detailed installation instructions and guidelines.
Table 7 lists the mechanical, electrical, and environmental properties of the Mercury Quantum 6600
Base Station.
Physical & Environmental
Specification
Dimensions
17.5” x 16.7” x 5.3” (44cm x 42cm x 13cm)
Weight
32lbs (14.5kg) (does not include mounting hardware)
Power
-48 VDC (150 Watts Max)
Temperature
-40C to +55C (ETSI EN 300 019-1.4 Class 4.1E)
Humidity
5-100% non-condensing
Altitude
To 10,000 ft above sea level
