that the LEDs can be turned off by the operator using the PureView NMS, the Web Interface, or the
Base Station’s command-line interface.
2.3.2 Radio and Physical Layer Specifications
The Mercury Quantum Family of Base Stations is available in several models to support a variety of
frequency bands and the regulatory requirements of a number of countries. Because several
deployment-specific variables (e.g., antenna type, cable type and length, settings, etc) can affect the
effective power output and other characteristics of the system, it is the customer’s responsibility to
assure that each deployment of this product meets applicable regulations. The PureView NMS, the
Web UI, and the CLI all provide guidelines and feedback to ensure an appropriate installation.
Table 3 lists key radio-related specifications of Mercury Quantum Base Stations. Note that additional
features, not listed, may be released in future software revisions.
Parameter
Specification
Frequency Bands
6623: 2.30-2.40 GHz
6625: 2.50-2.70 GHz
6633: 3.30-3.40 GHz
6635: 3.40-3.60 GHz
6635-IC: 3.45-3.65 GHz
6636: 3.65-3.70 GHz
Channel Sizes
3.5 MHz
5 MHz
7 MHz
10 MHz
Duplex Method
TDD
DL:UL Ratios
35:12, 29:18, 32:15, 26:21 (5 MHz and 10 MHz)
23:9, 21:12, 17:15 (3.5 MHz and 7 MHz)
Number of Tx/Rx Antennas
6 Tx, 6 Rx
Tx Power per Antenna
33dBm (RMS data power at maximum MCS level, measured at each
external antenna connector of the Base Station)
Permutation
PUSC
Modulation Rates
QPSK-1/2, QPSK-3/4
16QAM-1/2, 16QAM-3/4
64QAM-1/2, 64QAM-2/3, 64QAM-3/4, 64QAM-5/6
Data Repetition Coding
QPSK-1/2 Repetition 2, 4, 6
MAP Repetition
1, 2
