Figure 105 Typical Voice and Data Client Profile
By default, the Base Station is pre-configured with several profiles for Classifier, HARQ,
ARQ, QoS and Client. The User has the complete freedom and flexibility to use these pre-
defined profiles or they can edit accordingly.
At the Main Web GUI Interface Screen select the Configuration Tab and then the serviceprofile Main
Menu Option. This window details the information for the service profile Main Menu Option. There are
five Main Menu Sub-Elements and window is split into five main grouping sections (Figure 106). The five
main grouping sections provide a summary of the information that can be obtained by selecting and
navigating down into the Main Menu Sub-Element level.
Figure 106 Service Profile Menu Option
The Main Menu Sub-Elements are:
• cls-profile. These are the Classifier profiles.
• harq-profile. These are the Hybrid ARQ (automatic recovery) profiles.
• arq-profile. These are the ARQ profiles.
• qos-profile. These are the Quality of Service profiles.
• client-profile. These are the Client profiles.
• vlan-profile. VLAN configuration profiles.
