which the tool identifies as capturing on the clock’s trailing edge will not
propagate the clock effect cone. During the Setup system mode, this
information is not available and the tool assumes all state elements capture
with the leading edge of the selected clock.
• Analysis [Control | Observe] (FlexTest Only)
A literal that sets gate reporting to display control or observe data learned from
the fault analysis done with the Analyze Fault command
Control — A literal specifying Report Gate command to display the gate
values needed to excite the faultsite.
Observe — A literal specifying the Report Gate command to display the
gate values needed to detect the fault.
• Drc_pattern procedure_name [-All | time]
Two literals and an optional time triplet that specifies the name of the
procedure and the time in the test procedure file that the Report Gates
command uses to display a gates simulated value.
You must set the Drc_pattern prior to rules checking and you must re-execute
the design rules checking process, otherwise no data (-) from this option will
be available for gate reporting.
The valid choices for use with Drc_pattern are as follows:
procedure_name — A literal that specifies a procedure in the test
procedure file that you want the Report Gates command to use when
displaying the value of a gate. The literal choices for the procedure_name
option are as follows:
Test_setup — A literal specifying use of the test_setup procedure. In
the test procedure file, this procedure sets non-scan elements to the state
you desire for the load_unload procedure.
Load_unload — A literal specifying use of the load_unload procedure.
The test procedure file must contain this procedure which describes how
to load and unload data in the scan chains.
SHIft — A literal specifying use of the shift procedure. The test
procedure file must contain this procedure which describes how to shift
data one position down the scan chain.
