FastScan and FlexTest Reference Manual, V8.6_4
2-492
Set Gate Report Command Dictionary
Arguments
• Normal
A literal that specifies for the Report Gates command to display only its
standard information. This is the default mode upon invocation of the tool.
• Race (FlexTest Only)
A literal that specifies for the Report Gates command to display the simulated
values of the gates for race conditions. To make the race conditions reportable,
you must first use the Analyze Race command to check for race conditions
between clock and data signals.
The Report Gates command displays any one of five possible simulated values.
These values are: S, N, 0, 1, or Z, where S (same) indicates an unknown value
that remains unchanged since the previous timeframe, and where N (new)
indicates an unknown value that changes after the previous timeframe.
• Trace
A literal that specifies for the Report Gates command to display the simulated
values of the gates during the scan chain tracing. The format of these values
depends on the contents of the shift procedure. If the shift procedure contains
additional frames, the additional frames will also be displayed in the gate
report data. The trace data relates to the simulation performed during the scan
chain tracing. Use the Trace option to determine why a scan chain was not
properly sensitized during the shift procedure.
See the Examples section of this command for an example of the information
displayed.
• Error_pattern
A literal that specifies for the Report Gates command to display the simulated
value of the gates and its inputs for the pattern at which an audit error occurred.
• Fault_status (FastScan Only)
A literal that specifies for fault detection status of both SA-0 and SA-1 of all
gates to be preserved. Subsequent commands which cause the gate to be
displayed, will annotate the pins with fault status data. Therefore, in the case
that a schematic is currently displayed in DFTInsight and the user changes the
gate report data (by issuing the Set Gate Report command), all fault sites will
be annotated by the fault detection status.
