Command Dictionary Save Patterns
FastScan and FlexTest Reference Manual, V8.6_4
2-407
If you use the -External or the -Begin and -End switches, thereby not saving
all the internal patterns, the tool does not include test coverage and fault
information in the ASCII pattern set.
-BInary — (FastScan only) A switch that writes the patterns in binary
format.
The simulation and test format switch choices are as follows:
-LSIM — A switch that writes the patterns in the LSIM test vector format.
This is a serial format so, you must also specify the -Serial switch; failure to
do so results in the command using the -Parallel default which generates an
error. You can simulate the LSIM format patterns by using the LSIM IC
simulator.
-MGcwdb — A switch that writes the patterns in the Mentor Graphics
Waveform Database format and creates a dofile.
The Mentor Graphics Waveform Database format contains scan patterns, in
terms of events, and related timing information. You can use this format
with Mentor Graphics tools like QuickSim II and QuickFault II.
The dofile that the -Mgcwdb switch creates is a QuickSim II dofile with the
name <filename>.wdb.do. QuickSim II uses this dofile to load the
appropriate waveform databases, define the input and output pins, run the
simulator, compare the output waveforms with the expected output
waveforms, and print out a report containing information about any
differences.
-TSSIWgl — A switch that writes the patterns in the TSSI WGL format.
The TSSI WGL format contains the waveform pattern information and any
timing information from the timing file. You can use the TSSI WGL format
patterns to generate test patterns in a variety of tester and simulator formats.
-TSSIBinwgl — A switch that writes the patterns in the TSSI Binary WGL
format. The TSSI Binary WGL format contains the waveform pattern
information and any timing information from the timing file.
-Verilog — A switch that writes the patterns in the Verilog format. The
Verilog format contains pattern information and timing information from
the timing file as a sequence of events. You can use the Verilog format
patterns to interface to the Verilog-XL and Verifault simulators.
-VHdl — A switch that writes the patterns in the VHDL format.
