Command Dictionary Command Summary
FastScan and FlexTest Reference Manual, V8.6_4
2-7
Delete LFSRs
•
Removes the specified Linear Feedback Shift
Registers (LFSRs).
Delete Lists
••
Removes the specified pins from the pin list
that the tool monitors while in the Fault or
Good simulation system mode.
Delete Mos Direction
••
Resets the VDD or GND net in the Spice
design and library.
Delete Net Property
••
Resets the VDD or GND net in the Spice
design and library.
Delete Nofaults
••
Removes the nofault settings from either the
specified pin or instance/module pathnames.
Delete Nonscan
Handling
•
Removes the overriding learned behavior
classification for the specified non-scan
elements.
Delete Notest Points
•
Removes the circuit points which the tool
cannot use for testability insertion from the
specified pins.
Delete Observe Points
•
Removes observe points from the specified
pins.
Delete Output Masks
•
•
Removes the masking of the specified
primary output pins.
Delete Paths
•
Removes the specified path delay faults from
the current fault list.
Delete Pin Constraints
••
Removes the pin constraints from the
specified primary input pins.
Table 2-1. Command Summary [continued]
Command
D
F
T
I
F
S
F
T
Description
