FastScan and FlexTest Reference Manual, V8.6_4
2-252
Read Modelfile Command Dictionary
Read Modelfile
Tools Supported: FastScan and FlexTest
Scope: Setup mode
Usage
REAd MOdelfile modelfile_name RAM/ROM_instance_name
Description
Initializes the specified RAM or ROM gate using the memory states contained in
the named modelfile.
The Read Modelfile command sets the initial memory states of a RAM or ROM
gate using the data that you provide in a modelfile. You can create a modelfile
from within the library cell or by using the Write Modelfile command. The
modelfile must contain initialization data that is in the Mentor Graphics modelfile
format.
You specify the RAM or ROM gate that you want to initialize by using its
instance name. An error condition occurs if the instance contains multiple
RAM/ROM gates. When you issue the command, the flattened model may not be
available, so the tool checks for the correctness of the instance name and the
modelfile name during rules checking.
You may also initialize memory states of a RAM or ROM gate by specifying the
modelfile from within the RAM or ROM model description. To do so you use the
init_file attribute. For more information about modeling RAMs and ROMs and
the init_file attribute, refer to the “RAM and ROM” subsection of the Design-for-
Test: Common Resources Manual.
Modelfile Format
A Mentor Graphics modelfile contains addresses and data. You must present the
addresses in hexadecimal format. You can specify a range of addresses such as,
0-1f. An address range can contain an asterisk (*) wildcard character. For
example, to specify that you want all addresses set to a hexadecimal F, use “* / f;”.
You cannot use an X in an address.
You can present the data in either binary or hexadecimal format; the default is
hexadecimal. To specify data in binary format, you must add a ‘%’ to the
