Operating instructions

UP/BP/ULP/SLP 400 – 800 5
2 The equipment of MEMMERT cabinets Series UP, BP, ULP, SLP consists of:
 an electronic fuzzy-supported microprocessor PID process controller with
programmable heating and cooling ramps, set temperature operation and loop function.
The controller features continuous power adjustment as well as a time-saving self-
diagnostic system for the quick detection of faults (see check list).
One programme held in the internal memory can include up to 9 segments and is
stored in the controller even if there is a power failure. The external Memory Card XL
can carry up to 40 segments.
 The fan (in Type L units) is adjustable
 a built-in timer for digital programme time selection up to 999 hours, as well as an
alphanumeric display
 the air flap can be adjusted by means of a servomotor.
 parallel printer interface for high-resolution graphic or numerical printout on an external
EPSON ESC/P2 compatible printer
 A pre-formatted blank Memory Card XL with a memory
capacity of 32 kByte.
Reprogramable for up to 40 ramp segments and additionally
270 hours of protocol storage, with 1 minute sampling
interval.
 Memory Card XL reader built into the oven
 RS232C interface for heating programmes controlled or recorded by chip card or
computer. An RS485 interface is also available to special order.

With the MEMMERT software Celsius 2000, consisting of
installation diskette and operating manual, the controller
can be operated remotely via a PC.
Special accessory( to be ordered separately )

Temperature profile write/read device for PC
