User manual

ConnectX-2 Ethernet Card User Manual Rev 1.6
Mellanox Technologies
5
List of Figures
Figure 1: SFP+ NIC Component Side and Bracket Views 12
Figure 2: Card Product Label 14
Figure 3: Port Numbering 16
Figure 4: LED - Port Association 17
Figure 5: Physical and Logical Link Indications 17
Figure 6: I2C Connector 18
Figure 7: Flash Jumper 19
Figure 8: Support Download Assistant 24
Figure 9: Hardware Devices 27
Figure 10: PCI Device 28
Figure 11: Module With Locking Mechanism Closed 32
Figure 12: Module With Locking Mechanism Open 32
Figure 13: Schematic of the ConnectX-2 Small Form Factor MNPH29D Adapter Card 36
Figure 14: Schematic of the ConnectX-2 Card MNPH29C Adapter Card 37
Figure 15: Compatible Connector Plug and Pinout 40
Figure 16: Rear View of Module With Pin Placement 41
Figure 17: Remove the Bracket 43
Figure 18: Putting on the Bracket 44
