User manual

Adapter Card Interfaces
Rev 1.6
Mellanox Technologies
20
76 VPD Keyword V0 STR Misc Information
78 Length 0x10
79 Data PCIe Gen2 x8 STR_SPC
95 VPD Keyword RV STR
97 Length 0x1
98 Data 0,97 %CS0
99 Large Resource Type VPD-W Tag
(0x11)
0x91
100 Length [7:0] LSB 0x99
101 Length [15:8] MSB 0x00
102 VPD Keyword V1 STR EFI Driver version
104 Length 0x6
105 Data N/A STR_SPC
111 VPD Keyword YA STR Asset Tag
113 Length 0x20
114 Data N/A STR_SPC “N/A”
146 VPD Keyword RW STR Remaining read/write area
148 Length 0x6A
149 Data STR_ZERO Reserved (0x00)
255 Small Resource Type END Tag (0x11) 0x78
Table 8 - VPD Layout for MNPH29C-X[ST]R
Offset
(Decimal)
Item Value Format Description
0 Large Resource Type ID String Tag (0x02) 0x82
1 Length [7:0] LSB 0xE
2 Length [15:8] MSB 0x0
3 Data Hawk Dual Port STR
17 Large Resource Type VPD-R Tag (0x10) 0x90
18 Length [7:0] LSB 0x4F
19 Length [15:8] MSB 0x00
20 VPD Keyword PN STR Add in Card Part Number
22 Length 0x15
23 PN PN %STR_SPC
44 VPD Keyword EC STR Engineering Change Level of
the card (rev)
46 Length 0x2
47 Revision RV %STR PCB revision
49 VPD Keyword SN STR Serial Number
51 Length 0x18
52 SerialNumber %STR_SPC “00..00XXXX..XX”
Table 7 - VPD Layout for MNPH29D-X[ST]R
Offset (Decimal) Item Value Format Description
