ConnectX-2 Ethernet Card User Manual Rev 1.6

Mellanox Technologies

1.2 Mellanox Part Numbering Legend

Table 4 describes the Mellanox Technologies adapter cards part numbering legend.

For example, the part number MNPH29C-XTR describes Mellanox Technologies’ ConnectX EN

adapter card with two SFP+ ports, a PCIe2.0 x8 5.0GT/s interface, no on-board memory (mem-

free), a tall bracket, and RoHS R6 compliance. Using the legend,

• field M = M to indicate a Mellanox Technologies product,

• field H = N to indicate a Network Interface Card,

• field T = P to indicate 10GBASE-SR/LR,

• field S = H to indicate ConnectX

• field # = 2 to indicate two ports,

• field I = 9 to indicate PCI Express 2.0 x8 running at 5.0GT/s,

• field G = C to indicate Generation C ConnectX-2

• field X = X to indicate no on-board memory,

• field B = T to indicate a tall bracket, and

• field R = R to indicate RoHS R6 compliance

Table 4 - Mellanox Cards Part Numbering Key

Adapter Card

OPN

MHTS#I-XBR

Field Decoder

M Mellanox

Technologies

H Adapter Type H = InfiniBand Host Channel Adapter, N = Ethernet Network Interface Card

T Media P = SFP+,

S Adapter

Architecture

H = ConnectX

or ConnectX-2

# # ports 1 = 1, 2 = 2

I Host Interface X = PCI-X, 4 = PCIe x4, 8 = PCIe Gen1 x8, 9 = PCIe (Gen2 x8),

G Generation <blank> = Initial product generation, B= generation B, C= generation C

- Separator

X Memory Size X = MemFree, 1=128MB, 2=256MB, 3=512MB

B Bracket S = Short, T = Tall, N = None

R RoHS <blank> = non RoHS, C = RoHS R-5 w/ Exemption, R = RoHS R-6 Lead-Free
