1.1 Adapter Cards Covered in this Manual
Table 3 lists the Ethernet adapter cards described in this manual.
Table 3 - Network Interface Cards
Ordering Part
Number (OPN)
PCI Express
SERDES
Speed
Data Transmission
Rate/
# of ports
Short / Tall
Bracket
RoHS Adapter IC Part Number
MNPH29D-XTR PCIe Gen2
5.0 GT/s
10 +10 Gb/s
Ethernet
2 ports
Tall R-6 MT25408B0-FCCR-TE
MNPH29D-XSR PCIe Gen2
5.0 GT/s
10 +10 Gb/s
Ethernet
2 ports
Short R-6 MT25408B0-FCCR-TE
MNPH29C-XTR PCIe Gen2
5.0 GT/s
10 +10 Gb/s
Ethernet
2 ports
Tall R-6 MT25408B0-FCCR-TE
MNPH29C-XSR PCIe Gen2
5.0 GT/s
10 +10 Gb/s
Ethernet
2 ports
Short R-6 MT25408B0-FCCR-TE
