- ConnectX®-2 EN Dual Port SFP+ Ethernet Adapter Card User Manual
- Table of Contents
- List of Figures
- List of Tables
- Revision History
- About this Manual
- 1 Overview
- 2 Adapter Card Interfaces
- 3 Driver Software and Firmware
- 4 Ethernet Adapter Card Installation
- Appendix A: Specifications
- Appendix B: Interface Connectors Pinout
- Appendix C: Replacing a Tall Bracket With a Short Bracket
- Appendix D: Avertissements de sécurité d’installation (Warnings in French)
- Appendix E: Sicherheitshinweise (Warnings in German)
- Appendix F: Advertencias de seguridad para la instalación (Warnings in Spanish)
Overview
Rev 1.6
Mellanox Technologies
10
1 Overview
This document is a User Manual for Mellanox Technologies cards based on the ConnectX
®
-2
ENintegrated circuit device. The cards described in this manual have the following main features:
• IEEE Std 802.3 compliant
• 10 Gb/s Ethernet
• Dual SFP+ ports for connection Ethernet traffic
• PCI Express 2.0 (1.1 compatible) through an x8 edge connector up to 5GT/s
• Fiber Channel encapsulation (FCoE)
• RDMA over Converged Ethernet (RoCE)
•RoHS-R6
• Two bracket heights: short and tall
